The Saturn-H1300 Series integrates easily with fingerprint authentication, facial authentication, RFID card and QR code verification. fitting smoothly into your existing access control setup. Its bi-directional operation can be independently configured as controlled, locked, or free rotation, ensuring adaptable security for any environment. Saturn-H1300 Series is equipped with red and green LED indicators which provide clear visual guidance for users.
Also, the Saturn-H1300 is a high-security pedestrian access gate engineered for mobility — directly overcoming the key limitation of traditional full-height turnstiles, which are fixed and difficult to relocate. Designed for temporary access control, rapid deployment, and convenient transportation, it can be quickly disassembled into compact modules and redeployed across multiple sites, making it the practical choice wherever perimeter security needs change.
| Model Name | Saturn-H1300 |
| Audio Indicator | N/A |
| Visual Indicator | LED visual indicators integrated into the vertical column Red cross: passage denied Green arrow: passage allowed |
| Display | N/A |
| Lane Type | Single lane |
| Lane Width | 600mm |
| Lane Height | 2265 |
| Footprint (L*W) | 1400*1190 |
|
Rotor Movement Type |
Full-height rotating turnstile |
| Rotor Arm Configuration | 3-blade rotor |
| Rotor Diameter | 38mm |
| Rotor Arms | 9 |
| Throughput Rate | Max. 20 to 25 people per minute |
| Clutch | N/A |
| Rotor Arm Material | Stainless steel |
| Cabinet Material | SUS304 stainless steel (the housing features a precision 240# hairline finish) / (SUS316 stainless steel optional) |
| Lid Material | SUS304 stainless steel (the housing features a precision 240# hairline finish) / (SUS316 stainless steel optional) |
| IR Sensors | N/A |
| Motherboard Function | System confguration, entry log memory, safety logic |
| Motherboard Communication | Fire alarm port (Relay)*1, RS485 port*1 |
| Controller | Standard full height turnstile controller |
| Credential Options | RFID reader: ProID10; Fingerprint reader: FR1500S or 3rd-party readers QR Code reader: QR500 Compatible with ZKTeco and third-party facial recognition standalone access control terminals |
| Flow Rate | RFID: 20 passengers per minute Fingerprint: 15 passengers per minute QR Code: 20 passengers per minute Facial Authentication: 15 passengers per minute |
| Accessibility | 600mm (23.62") standard lane for pedestrians |
| Power Supply | 100-120VAC or 200-240VAC, 50/60Hz |
| Power Rating | 40W |
| Noise Level | Less than 60 dB |
| MCBF | 2million |
| Weight | Net Weight: 152kg Gross Weight: 198kg |
| Dimension (L*W*H) | 1400*1190*2265mm |
| Dimensions with Packing ( L*W*H ) | 2150*760*703mm |
| Operating Temperature | -28°C to 60°C |
| Operating Humidity | 0% to 95% RH (non-condensing) |
| Certifications | IPX4 |
| Supported Software | ZKBio CVSecurity (depends on the access controller installed) |
| Safety Features | Emergency escape function |
| Security Features | Anti-pass back, Anti-tailgating |
| Product Delivery | Pre-assembled for easy installation |
| Application Environment | Indoor and Covered Outdoor |
| Site Preparation | Flat and level finished floor (optional base plate for unfinished floors) |
| Security Level | High |
| Emergency Mode | Rotor unlocks automatically during emergencies |
| Packing Material | Wooden Box |
| Warranty | 1 year |
