TBM01 / 02

Ticket Dispenser

ZKTeco develops TBM01/02 ticket dispenser which supports microwave radar system, offers an efficient contact-less ticketing system. TBM01/02 has various verification methods, including open bar-code scanning reader and card swiping. This ticket box helps avoiding cross infected during the pandemic. Moreover, TBM01/02 ticket box contactless ticketing function works best for temporary parking, regular-parking induction card and motor-cycle lanes. With thermal TBM01/02 ticket box is widely used in supermarkets, communities, government buildings and other places.

  • Micro wave radar induction contact-less ticket

  • Compatible with UHF,ID/IC

  • Equipped with high-brightness LED

  • High-precision long distance 2D scan reader

  • Support for charging at central payment point

Model

TBM01

TBM02

Offline Working Parameters



Allowlist

1000

Blocklist

1000

Monthly Parking

8000

Entry and Exit Records

1000

Communication Protocol

TCP/IP Wiegand

Material

Cold rolled sheet

Support card type (Optional)

IC, ID, UHF

Protection Level

IP65

Recognition Trigger

loop detection (by default)

Working Voltage

220V

Number of sheets printed per roll

About 800

Power

100W Max

Working Humidity

≤90%

Working Temperature

-15°C to 55°C

Dimension

288*360*1380(mm)

Weight

32KG
